Description
PW-UCD128-40M Computer Control Constant Temperature & Humidity Tensile Strength Testing Machine
Designed for laboratories and quality assurance teams, this universal testing machine constant temperature and humidity tensile testing machine offers environmental simulation combined with mechanical force measurements. Its multifunctional capabilities as a tensile strength testing machine enable tensile, compression, tearing, shearing, and peeling assessments under variable climate conditions. Target users include research institutions, material developers, and manufacturing quality control departments requiring reliable, repeatable testing results. The removable environmental chamber extends usability for room temperature measurements while maintaining high operational flexibility. Such integration supports comprehensive analysis across a broad range of material types and testing demands.
Equipped with a computerized tensile tester interface, the universal tensile testing machine tensile testing machine delivers high precision force resolution at 1/250,000, with force accuracy maintained within ±0.5%. Its temperature regulation system uses PID control, achieving ±1℃ stability across a range from -70℃ to 150℃, while humidity control ensures consistent ambient replication. The machine supports diverse force unit conversions and has automated safety stops for overloads or specimen damage. An advanced servo motor combined with a precision ball screw drive provides smooth and adjustable test speeds ranging from 0.5 to 500 mm/min. The stainless-steel chamber and removable temperature box facilitate durability and ease of maintenance, supporting robust data acquisition.
This tensile strength testing machine excels in various sectors requiring environmental durability evaluation, including polymer research, textile manufacturing, electronics, and automotive material development. Its ability to simulate real-world combinations of temperature and humidity while performing tensile, bending, or adhesion tests makes it invaluable for product validation and certification workflows. The universal testing machine constant temperature and humidity tensile testing machine contributes to predictive material behavior modeling, enabling R&D teams to optimize formulations and enhance compliance with industry standards. Additionally, its data output supports comprehensive reporting suited for regulatory submissions and internal process controls.
| Capacity | 10N, 20N, 50N, 100N, 200N, 500N, 1KN, 2KN, 5KN, 10KN ( can select double capacities reparation) |
| Temperature Range | 0, -20, -40, -60, -70℃~150℃ |
| Display | Computer display mode |
| Force Resolution | 1/250,000 |
| Force Accuracy | ≤±0.5% |
| Stroke Resolution | 0.005mm |
| Control Mode | Tensile tester all computerized operation mode |
| Temp. Control | PID automatic calculation, stable error |
| Display Accuracy | 0.1℃ |
| Temp. Accuracy | ±1℃ |
| Circulation System | Fan force circulation system |
| Heating System | stainless steel heat radiation type of heater |
| Cooling System | Fan cooling type, high-efficiency compressor, environmental protection cooling medium |
| Protection Device | Leakage and overload protector, compressor over protector, humidifier temperature protection, temperature limit protection device |
| Chamber Material | SUS#304 stainless steel |
| Test Stroke | 1300mm (after removing chamber, stand-alone operation and use tensile machine) |
| Test Width | 720mm (after removing chamber, stand-alone operation and use tensile machine) |
| Test Speed | 0.5~500mm/min, can set by computer, with up & down fast adjustment button of grips |
| Force Unit Switch | Kgf, N, Ibf, g, ton, Mpa |
| Stop Mode | Overload stop, emergency stop button, specimen damage automatic stop, upper & lower limit set automatic stop, automatic reset function |
| Machine Dimension | 110×160×220cm(W×D×H) |
| Machine Drive | Servo motor drive, synchronous wheel and precision ball screw drive |
| Power | 400W |
| Machine Weight | Approx 420kg |
| Power Supply | 220V 50/60HZ 30A |
| Standard Device | Extension pole of grips, heat abstractor, 1 set of grips, computer software, USB computer connection wires |
| Optional | Personal computer |
FAQ
Can your tensile strength testing machine handle different material types?
Yes, our tensile strength testing machine supports a wide range of materials by offering multiple test modes including tensile, compression, tearing, and peeling. This versatility allows precise evaluation of mechanical properties across various industrial materials under controlled temperature and humidity.
Do you offer customization options for specific testing requirements?
We provide configurable features such as selectable force capacity (10N to 10kN), removable temperature box for room temperature testing, and multiple force unit options. This ensures our universal tensile testing machine meets your precise application needs and testing standards.
What installation support do you provide with this tensile tester?
We include detailed computer software and USB connection wires for easy setup. Our technical team offers guidance to integrate the tensile tester into your workflow and assists with configuration of PID-controlled temperature and force parameters to ensure accurate, repeatable results.
How do you ensure the durability and safety of the constant temperature and humidity tensile testing machine?
Our equipment features protection devices against leakage, overload, compressor issues, and temperature anomalies. Built with SUS#304 stainless steel and precision servo motor drives, our constant temperature and humidity tensile testing machine guarantees reliable, long-term operation in demanding environments.
